38
GR6
12. Secure the 2.5-inch extension bay with four screws.
2.5-inch HDD/SSD and extension bay assembly
Drive bay SATA connector
HDD/SSD SATA connector
11. Carefully place the 2.5-inch HDD/SSD and extension bay
assembly into the drive bay and then slide it towards the SATA
connector.
