Asus WS C621E SAGE Series User Manual

xi
(continued on the next page)
WS C621E SAGE Series specifications summary
Model Name WS C621E SAGE WS C621E SAGE (BMC)
USB
ASMedia USB 3.1 Controllers
- 1 x USB 3.1 Type A port at back panel
- 1 x USB 3.1 Type-C™ port at back panel”
Intel
®
C621 Chipset
- 8 x USB 3.0 (4@ back panel, 4@ mid-board )
- 4 x USB 2.0 Ports (2@ back panel, 2@ mid-board)”
Audio
Realtek
®
ALC S1220A 8-Channel High Definition Audio CODEC
- Impedance sense for front and rear headphone outputs
- Supports : Jack-detection, Multi-streaming, front Panel MIC Jack-
retasking
- High quality 120 dB SNR stereo playback output and 113 dB SNR
recording input (Line-in)
- Front panel audio connector (AAFP)
- Supports up to 32-Bit/192kHz playback*
Audio Feature:
- DTS Connect
- DTS Headphone:X
- Premium Japanese-made audio capacitors: Provide warm, natural
and immersive sound with exceptional clarity and delity
- Unique de-pop circuit: Reduces start-up popping noise to audio
outputs
- Power pre-regulator: Reduces power input noise to ensure consistent
performance
* Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for
8-Channel audio. 32-Bit/192kHz is only available under Windows
®
10.
Workstation Unique
Features
- 7 x PCIe x16 slots
- 10K hours Capacitors
- ProCool Power Connector
- Dr. Mos
- USB BIOS Flashback
- Beat Thermal Choke
- Digi+ VRM
- ASUS PIKE card (Optional)
- 7 x PCIe x16 slots
- 10K hours Capacitors
- ProCool Power Connector
- Dr. Mos
- USB BIOS Flashback
- Beat Thermal Choke
- Digi+ VRM
- ASUS PIKE card (Optional)
- BMC Remote Management

Asus WS C621E SAGE Series Specifications

General

CPU Support	Intel Xeon Scalable Processors
Chipset	Intel C621
Memory Slots	12 x DIMM
Form Factor	CEB
CPU Socket	LGA 3647
Memory Support	DDR4
Maximum Memory	768GB
Network	Dual Intel I210 Gigabit LAN
