2.3 Motherboard rear and audio connections
2.3.1 Rear I/O connection
• USB3.0/3.1devicescanonlybeusedasdatastorageonly.
• Westronglyrecommendthatyouconnectyourdevicestoportswithmatchingdata
transferrate.PleaseconnectyourUSB3.0devicestoUSB3.0portsandyourUSB
3.1devicestoUSB3.1portsforfasterandbetterperformanceforyourdevices.
* and **: Refer to the tables on the next page for LAN port LEDs and audio port definitions.
Rear panel connectors
1. PS/2andkeyboardMouseport
2. USBBIOSFlashbackbutton
3. USB3.1Type-AportEA2
4. LAN(RJ-45)ports1,2*
5. USB2.0ports9,10.LowerportsupportsUSBBIOSFlashbackfunction.
6. USB3.1Type-C™portEC1
7. USB3.0ports3,4
8. USB3.0ports1,2
9. OpticalS/PDIFOUTport
10.. AudioI/Oports**
