Asus WS C621E SAGE Series User Manual

3-8
Chapter 3: BIOS Setup
Chapter 3
Ai Overclock Tuner
AllowsyoutoselecttheCPUoverclockingoptionstoachievethedesiredCPUinternal
frequency.
Congurationoptions:[Auto][Manual][OCTune]
The following item appears only when you set the Ai Overclocking Tuner to [Manual].
BCLK Frequency
ThisitemallowsyoutosettheBCLK(baseclock)frequencytoenhancethesystem
performance. Use the <+> or <-> to adjust the value. The values range from 80.0 MHz
to 300.0 MHz.
WerecommendyoutosetthevaluebasedontheCPUspecication,ashighBCLK
frequencies may damage the CPU permanently.
The following item appears only when you set the Ai Overclocking Tuner to [OC Tune].
OC Tune Level
AllowsyoutoselecttheOCTuneLevel.
Congurationoptions:[Level1][Level2][Level3]
3.3 Main menu
WhenyouentertheBIOSSetupprogram,theMainmenuscreenappears.TheMainmenu
provides you an overview of the basic system information, and allows you to set the system
date and time.
3.4 Ai Tweaker menu
TheAiTweakermenuitemsallowyoutocongureoverclocking-relateditems.
BecautiouswhenchangingthesettingsoftheAiTweakermenuitems.Incorrecteld
values can cause the system to malfunction
ThecongurationoptionsforthissectionvarydependingontheCPUandDIMMmodelyou
installed on the motherboard.

Asus WS C621E SAGE Series Specifications

General

CPU Support	Intel Xeon Scalable Processors
Chipset	Intel C621
Memory Slots	12 x DIMM
Form Factor	CEB
CPU Socket	LGA 3647
Memory Support	DDR4
Maximum Memory	768GB
Network	Dual Intel I210 Gigabit LAN
