Asus WS C621E SAGE Series User Manual

3-10
Chapter 3: BIOS Setup
Chapter 3
The following item appears only when you set Serial Port to [Enabled].
Change Settings
Allows you to choose the setting for Super IO device.
Congurationoptions:[Auto][IO=3F8h;IRQ=4;][IO=3F8h;IRQ=3,4,5,6,7,9,10,11,
12;][IO=2F8h;IRQ=3,4,5,6,7,9,10,11,12;][IO=3E8h;IRQ=3,4,5,6,7,9,10,11,
12;][IO=2E8h;IRQ=3,4,5,6,7,9,10,11,12;]
3.5.6 Onboard LAN Configuration
TheitemsinthismenuallowyoutoconguretneonboardLANparameters.
Onboard I210 LAN Configuration
Intel LAN1 Enable
AllowsyoutoenableordisabletheIntelLAN.
Congurationoptions:[Disabled][Enabled]
The following item appears only when you set Intel LAN1 Enable to [Enabled].
Intel LAN ROM Type
AllowsyoutoselecttheIntelLANROMtype.
Congurationoptions:[Disabled][PXE][iSCSI]
Intel LAN2 Enable
AllowsyoutoenableordisabletheIntelLAN.
Congurationoptions:[Disabled][Enabled]
The following item appears only when you set Intel LAN2 Enable to [Enabled].
Intel LAN ROM Type
AllowsyoutoselecttheIntelLANROMtype.
Congurationoptions:[Disabled][PXE][iSCSI]
3.5.5 Serial Port Console Redirection
TheitemsinthismenuallowyoutoconguretheSerialPortConsoleRedirectionsettings.

Asus WS C621E SAGE Series Specifications

General

CPU Support	Intel Xeon Scalable Processors
Chipset	Intel C621
Memory Slots	12 x DIMM
Form Factor	CEB
CPU Socket	LGA 3647
Memory Support	DDR4
Maximum Memory	768GB
Network	Dual Intel I210 Gigabit LAN
