Chapter 1
Layout contents
Connectors/Jumpers/Buttons and switches/Slots Page
1. DDR4DIMMslots 1-5
2. CPU,front,andrearfanconnectors(4-pinCPU_FAN1-2;4-pinFRNT_
FAN1-5;4-pinREAR_FAN1-2)
1-25
3. LGA3647CPUsocket 1-4
4. ATXpowerconnectors(24-pinEATXPWR;8-pinEATX12V1;

8-pinEATX12V2;6-pinEATX12V3)
1-28
5. PowerSupplySMBusconnector(5-pinPSUSMB) 1-29
6. PMBus1.2PSUselectjumper(3-pinSMART_PSU1) 1-12
7. DDR4thermaleventsetting(3-pinDIMMTRIP1-2) 1-11
8. SATADOMpowersetting(3-pinDOM1_PWR1) 1-11
9. U.2connectors(U.2_1;U.2_2;U.2_3;U.2_4) 1-21
10. Intel
®
C621SerialATA6Gb/sconnectors(7-pinSATA1-8) 1-18
11. ASMedia
®
SerialATA6Gb/sconnectors(7-pinSATA_E1-2) 1-18
12. Auxiliarypanelconnector(20-2pinAUX_PANEL1) 1-27
13. ChassisIntrusionconnector(2-pinINTRUSION1) 1-20
14. Systempanelconnector(20-1pinPANEL1) 1-26
15. SerialGeneralPurposeInput/Outputconnector(6-1pinSGPIO1) 1-31
16. TPMconnector(14-1pinTPM1) 1-20
17. ClearRTCRAM(3-pinCLRTC1) 1-10
18. MErmwareforcerecoverysetting(3-pinME_RCVR1) 1-12
19. SystemManagementBus(SMBUS)connector(5-1pinSMBUS1) 1-30
20. VROC_KEYconnector(4-pinVROC_KEY1) 1-22
21. USB3.0connector(20-1pinUSB3_E12;20-1pinUSB3_E34) 1-24
22. PCH_MFG1Setting(3-pinPCH_MFG1) 1-13
23. M.2(NGFF)connectors(NGFF1) 1-22
24. VGAcontrollersetting(3-pinVGA_SW1) 1-13
25. USB2.0connector(10-1pinUSB78) 1-23
26. IPMISWsetting(3-pinIPMI_SW1) 1-14
27. VPP_I2C1connector(10-1pinVPP_I2C1) 1-30
28. Q-CodeLEDs 1-17
29. Resetbutton 1-9
30. Powerbutton 1-9
31. Serialportconnector(10-1pinCOM1) 1-29
32. VGAconnector(16-1pinVGA_HDR1) 1-21
33. Frontpanelaudioconnector(10-1pinAAFP) 1-19
34. HarddiskactivityLEDconnector(4-pinHDLED1) 1-19
35. BMCconnector(14-1pinASMB9)(forWSC621ESAGE(BMC)only) 1-31
36. MicroSDcardslot(MSD1) 1-32

Asus WS C621E SAGE Series Specifications

General

CPU Support	Intel Xeon Scalable Processors
Chipset	Intel C621
Memory Slots	12 x DIMM
Form Factor	CEB
CPU Socket	LGA 3647
Memory Support	DDR4
Maximum Memory	768GB
Network	Dual Intel I210 Gigabit LAN
