Asus WS C621E SAGE Series User Manual

ASUS WS C621E SAGE
1-27
Chapter 1
15. Auxiliary panel connector (20-2 pin AUX_PANEL1)
ThisconnectorisforadditionalfrontpanelfeaturesincludingfrontpanelSMB,locator
LEDandswitch,chassisintrusion,andLANLEDs.
1. Front panel SMB (6-1 pin FPSMB)
ThisconnectorconnectsthefrontpanelSMBuscable.
2. LAN activity LED (2-pin LAN1_LED, LAN2_LED)
TheseconnectorsarefortheGigabitLANactivityLEDsonthefrontpanel.
3. Locator LED (2-pin LOCATORLED1, 2-pin LOCATORLED2)
TheseconnectorsareforthelocatorLED1andLED2onthefrontpanel.Connectthe
LocatorLEDcablestothese2-pinconnector.TheLEDswilllightupwhentheLocator
buttonispressed.
4. Locator Button/Switch (2-pin LOCATORBTN)
Thisconnectorisforthelocatorbuttononthefrontpanel.Thisbuttonqueriesthestate
ofthesystemlocator.

Asus WS C621E SAGE Series Specifications

General

CPU Support	Intel Xeon Scalable Processors
Chipset	Intel C621
Memory Slots	12 x DIMM
Form Factor	CEB
CPU Socket	LGA 3647
Memory Support	DDR4
Maximum Memory	768GB
Network	Dual Intel I210 Gigabit LAN
