ASUS Xonar D2X
6.4.2 10-Band Equalizer
The equalizer can modify the audio output for different frequencies, and be used
to compensate for deficiencies in your speakers/systems. There are 12 default
patterns and you can also make your own settings.
No Item Description
1 Default Equalizer
Options
There are 12 available equalizer patterns. Click one to apply
it.
2 User Dened
You can click this button to apply your own defined
parameters saved in the pull-down menu.
3 Equalier Slider
Adjust the gain for each band (30~16KHz)
4 Save Name
Key in a name for your own “User Defined” equalizer setting
5 Add/Save
Click this + button to save the parameters into User Defined
list
6 Delete
Click this - button to delete the parameters from User
Defined list
13
2 4
5 6
