ASUSTeK COMPUTER ROG STRIX X299-E GAMING - Layout Contents

ROG STRIX X299-E GAMING
1-3
Chapter 1
Layout contents
Connectors/Jumpers/Buttons and switches/Slots Page
1. DDR4DIMMslots 1-5
2. CPU,CPUoptional,M.2,waterpump,AIO,extension,andchassisfan
connectors(4-pinCPU_FAN;4-pinCPU_OPT;4-pinM.2_FAN;4-pinW_
PUMP+;4-pinAIO_PUMP;5-pinEXT_FAN;4-pinCHA_FAN1-2)
1-22
3. RGBheader(4-pinRGB_HEADER1,RGB_HEADER2) 1-25
4. ATXpowerconnectors(24-pinEATXPWR;8-pinEATX12V_1;4-pin
EATX12V_2)
1-23
5. LGA2066CPUsocket 1-4
6. M.2Socket3 1-19
7. USB3.1Gen2frontpanelconnector(U31G2_E3) 1-20
8. USB3.1Gen1connectors(20-1pinU31G1_12,U31G1_34) 1-20
9. T_Sensorconnector(2-pinT_SENSOR) 1-21
10. Intel
®
X299SerialATA6Gb/sconnectors(7-pinSATA6G_12,
SATA6G_34,SATA6G_56,SATA6G_78)
1-18
11. VROC_HW_KEYconnector(4-pinVROC_HW_KEY) 1-27
12. ClearRTCRAMjumper(2-pinCLRTC) 1-11
13. CPUOverVoltagejumper(3-pinCPU_OV) 1-12
14. Systempanelconnector(20-3pinPANEL) 1-24
15. 3DMount 1-12
16. Addressableheader(4-1pinADD_HEADER) 1-26
17. USB2.0connectors(10-1pinUSB910) 1-21
18. Power-onbutton 1-10
19. Q-CodeLED 1-13
20. Serialportconnector(10-1pinCOM) 1-19
21. Frontpanelaudioconnector(10-1pinAAFP) 1-27
