ROG STRIX X299-E GAMING

2-3

Chapter 2

2.1.2 CPU installation

Please note the order in opening/closing the double latch. Follow the instructions printed on

the metal sealing hatch or the illustrations shown below in this manual. The plastic cap will

pop up automatically once the CPU is in place and the hatch properly sealed down.
