Getting started
6
Telephone base and charger installation
Install the telephone base and charger, as shown below. If you subscribe
to high-speed Internet service (DSL - digital subscriber line) through your
telephone line, you must install a DSL lter between the telephone line cord
and the telephone wall jack. The lter prevents noise and caller ID problems
caused by DSL interference. Please contact your DSL service provider for
more information about DSL lters.
The telephone base comes ready for tabletop use. If you want to mount your
telephone on a wall, refer to Wall-mount installation on pages 10-12
for details.
Plug the large end
of the charger’s
power adapter into
an electrical outlet
not controlled by a
wall switch.
Ensure the small
end of the charger’s
power adapter is
plugged into the
power jack on the
bottom of the
charger.
IMPORTANT INFORMATION:
Use only the power adapter(s) provided with this
product. To obtain a replacement, visit our website
at www.telephones.att.com or call
1 (800) 222-3111. In Canada, dial
1 (866) 288-4268.
Plug the large end
of the base power
adapter into an
electrical outlet not
controlled by a wall
switch.
Plug the small end
of the base power
adapter into the
power jack on
the bottom of the
telephone base.
Plug one end of the
telephone line cord into
a telephone wall jack.
A DSL lter (not included)
is required if you have DSL
high-speed Internet service.
Route the cords
through the slots.
Plug the other end of
the telephone line cord
into the telephone line
jack on the bottom of
the telephone base.
