Atari Super Breakout User Manual

TV MONITOR REMOVAL
1.
Unfasten
two
smooth
pan-head
bolts
from
the
control
panel
by
holding
down
the
bolt
heads
with
one
hand
and
using
the
other
hand
to
remove
the
wing
nuts.
These
wing
nuts
are
located
on
the
inside
of
the
cabinet,
and
can
be
reached
through
the
coin
door.
2.
Unplug
control
panel
Molex
connectors.
3.
Remove
control
panel.
4.
Slide
out
playfield
Plexiglas sh i·eld.
5.
Remove
cardboard
bezel.
6.
Remove
wood
TV
monitor
retainer
board.
7.
Unplug TV
monitor
chassis
connector.
8.
Slide
out
TV
monitor
shelf
through
rear
access
door.
-
