WALL MOUNTING INSTRUCTIONS
Remove the heater from the packaging and then remove the wall bracket from the
back of the heater by laying the heater face down and opening the lock with a flat
screwdriver.
1) Lift the locking tab with the screwdriver, 2) Push the bracket toward the base
of the heater.
3) Lift the Top of the bracket away from 4) Remove the bracket.
the heater
Kw 0.5/.75/1.0 1.5 2.0
A 218
B 130 292 402
All dimensions in mm
