ATEN CS692 User Manual

- 4 -
Package Contents
The CS692 USB HD Audio/Video KVM Switch package contains
the following items:
 1 CS692 USB HD Audio/Video KVM Switch with Remote
Port Selector
 2 Hotkey Stickers
 1 User Manual*
 1 Quick Start Guide
Check to make sure that all the components are present and that
nothing got damaged in shipping. If you encounter a problem,
contact your dealer.
Read this manual thoroughly and follow the installation and
operation procedures carefully to prevent any damage to the unit,
and/or any of the devices connected to it.
* Features may have been added to the CS692 since this
manual was printed. Please visit our website to download the
most up-to-date version of the manual.
Copyright © 2010–2013 ATEN
®
International Co., Ltd.
Manual Date: 2013-12-02 - Manual Part No. PAPE-1349-AT3G
ATEN and the ATEN logo are trademarks of ATEN International Co., Ltd. All rights
reserved. All other trademarks are the property of their respective owners.

ATEN CS692 Specifications

General

Console ports	3.5mm headphone, 3.5mm mic, HDMI, USB A
Audio connections	Yes
USB connector type	USB Type-A
Number of microphone inputs	3
Number of computers controlled	2
USB 2.0 Type-A hub ports quantity	4
Power source	DC
Power consumption (typical)	0.72 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 80 %
HD type	WUXGA
Scan interval	3, 5, 10, 20 s
Video bandwidth	60 Hz
Maximum resolution	1920 x 1200 pixels
Product color	Black
Rack mounting	No
Housing material	Plastic
Master (outer) case width	395 mm
Master (outer) case height	182 mm
Master (outer) case length	405 mm
Master (outer) case weight	6130 g
Harmonized System (HS) code	85176200
Master (outer) case net weight	4090 g
Quantity per master (outer) case	10 pc(s)
Package depth	163 mm
Package width	70 mm
Package height	235 mm
Package weight	550 g

Weight and Dimensions

Depth	66.5 mm
Width	82.4 mm
Height	25.2 mm
Weight	409 g
