ATEN CS692 User Manual

- 8 -
Operating Systems
Supported operating systems are shown in the table, below:
OS Version
Windows 2000 / XP / 2003 / 2008 / Vista / 7
Linux RedHat 9.0, Fedora and higher
SuSE 10 / 11.1 and higher
Debian 3.1 / 4.0
Ubuntu 7.04 / 7.10
UNIX FreeBSD 5.5 / 6.1 / 6.2
Novell Netware 6.0 / 6.5
Mac OS 9 and higher
DOS 6.2 and higher

ATEN CS692 Specifications

General

Console ports	3.5mm headphone, 3.5mm mic, HDMI, USB A
Audio connections	Yes
USB connector type	USB Type-A
Number of microphone inputs	3
Number of computers controlled	2
USB 2.0 Type-A hub ports quantity	4
Power source	DC
Power consumption (typical)	0.72 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 80 %
HD type	WUXGA
Scan interval	3, 5, 10, 20 s
Video bandwidth	60 Hz
Maximum resolution	1920 x 1200 pixels
Product color	Black
Rack mounting	No
Housing material	Plastic
Master (outer) case width	395 mm
Master (outer) case height	182 mm
Master (outer) case length	405 mm
Master (outer) case weight	6130 g
Harmonized System (HS) code	85176200
Master (outer) case net weight	4090 g
Quantity per master (outer) case	10 pc(s)
Package depth	163 mm
Package width	70 mm
Package height	235 mm
Package weight	550 g

Weight and Dimensions

Depth	66.5 mm
Width	82.4 mm
Height	25.2 mm
Weight	409 g
