ATEQ D6 Series User Manual

25 / 93
FG_D6_CCLINK_EN_02 / 2020-06-17
WRr/WRw = 16 words – Status & Real time measurements
Offset
(byte)
Length
(byte)
Offset
(word)
Read table
(MASTER ← ATEQ)
Write table
(MASTER → ATEQ)
8
2
04(h)
WRr00(h)
Number of FIFO results
WRw00(h)
Special cycle code
10
2
05(h)
WRr01(h)
Test type
WRw01(h)
RESERVED
12
2
06(h)
WRr02(h)
Relay status:
WRw02(h)
RESERVED
Bit 0 = 1 > Pass part (OK)
Bit 1 = 1 > Fail test part
(NOK)
Bit 2 = 1 > Fail reference part
(NOK)
Bit 3 = 1 > Alarm
Bit 4 = 1 > Pressure error
Bit 5 = 1 > Cycle end (system
ready)
Bit 6 = 1 > Part recoverable
Bit 7 = 1 > Calibration error
Bit 8 = 1 > not used
Bit 9 = 1 > ATR fault
Bit 10 to 15 > not used,
always at 0
14
2
07(h)
WRr03(h)
Step
WRw03(h)
RESERVED
Real time measurements
16
4
08(h)
Pressure value (32 bits integer)
Example: Pressure value = 207
On network : 98 28 03 00
00032898(H) → 207000(d)/1000 → 207
WRr04(h)
Low word (LSW)
WRw04(h)
RESERVED
WRr05(h)
High word (MSW)
WRw05(h)
RESERVED
20
4
0A(h)
Pressure unit (32 bits integer)
Example: Pressure unit Pa = 6
On network: 70 17 00 00
00001770(H) → 6000(d)/1000 → 6
WRr06(h)
Low word (LSW)
WRw06(h)
RESERVED
WRr07(h)
High word (MSW)
WRw07(h)
RESERVED
24
4
0C(h)
Flow value (32 bits integer)
Example: Flow value = -0.108
On network: 94 FF FF FF
FFFFFF94(H) → -108(d)/1000 → -0.108
WRr08(h)
Low word (LSW)
WRw08(h)
RESERVED
WRr09(h)
High word (MSW)
WRw09(h)
RESERVED
28
4
0E(h)
Flow unit (32 bits integer)
Example: Flow Unit Pa/s = 8
On network: 40 1F 00 00
00001F40(H) → 8000(d)/1000 → 8
WRr0A(h)
Low word (LSW)
WRw0A(h)
RESERVED
WRr0B(h)
High word (MSW)
WRw0B(h)
RESERVED
32
6
10(h)
WRr0C(h)
RESERVED
WRw0C(h)
RESERVED
…
…
WRr0F(h)
WRw0F(h)
