RX/RY = 4 words – Commands
Offset
(byte)
Length
(byte)
Offset
(word)
Read table
(MASTER ← ATEQ)
Write table
(MASTER → ATEQ)
0
2
00(h)
Command echo:
Command:
X000(h)
Echo reset
Y000(h)
Reset (stop current cycle)
X001(h)
Echo start
Y001(h)
Start (starting a test cycle)
X002(h)
Echo start special cycle
Y002(h)
Start special cycle
X003(h)
Echo program selection
Y003(h)
Program selection
X004(h)
RESERVED
Y004(h)
RESERVED
…
…
X00F(h)
Y00F(h)
2
2
01(h)
Command error code:
X010(h)
Error reset
Y010(h)
RESERVED
X011(h)
Error start
X012(h)
Error start special cycle
X013(h)
Error program selection
…
X014(h)
RESERVED
…
X01F(h)
Y01F(h)
4
2
02(h)
X020(h)
Refresh counter
Y020(h)
RESERVED
…
…
X02F(h)
Y02F(h)
6
2
03(h)
X030(h)
Number of current program
Y030(h)
Number of program to be
selected
…
…
X03F(h)
Y03F(h)
