ATEQ D6 Series User Manual

81 / 93
FG_D6_CCLINK_EN_02 / 2020-06-17
Extended results
The extended result structure contains 80 bytes.
Words
Meaning
*ERD Only
Type
Bytes
Coeff
1
Program number.
Word
2
2
Test type.
Word
2
3
Image of the relays:
Bit 0 = 1: pass part.
Bit 1 = 1: fail part, maximum flow reject.
Bit 2 = 1: fail part, minimum flow reject.
Bit 3 = 1: alarm.
Bit 4 = 1: unused.
Bit 5 = 1: reserved.
Bit 6 = 1: unused.
Bit 7 = 1: unused.
Word
2
4
Alarm code (refer to the alarm codes table).
Word
2
5
Pressure low part word.
Long
4
x1000
6
Pressure high part word.
7
Pressure unit code low part word (refer to units table).
Long
4
x1000
8
Pressure unit code high part word (refer to units table).
9
Flow low section word.
Long
4
x1000
10
Flow high section word.
11
Flow unit code low part word (refer to. Units table).
Long
4
x1000
12
Flow unit code high part word (refer to. Units table).
13
Step pressure low part word *
Long
4
x1000
14
Step pressure high part word *
15
Step pressure unit code low part word (refer to units table) *
Long
4
x1000
16
Step pressure unit code high part word (refer to units table) *
17
Step flow low part word *
Long
4
x1000
18
Step flow high part word *
19
Step flow unit code low part word (refer to units table) *
Long
4
x1000
20
Step flow unit code high part word (refer to units table) *
21
Drop pressure low part word *
Long
4
x1000
22
Drop pressure high part word *
23
Drop pressure unit code low part word (refer to units table) *
Long
4
x1000
24
Drop pressure unit code high part word (refer to units table) *
25
Pa – Pa/s Leak result low part word
Long
4
x1000
26
Pa – Pa/s Leak result high part word
27
Drop flow unit code low part word (refer to units table) *
Long
4
x1000
28
Drop flow unit code high part word (refer to units table) *
29
Rise contact pressure low part word *
Long
4
x1000
30
Rise contact pressure high part word *
31
Rise contact pressure unit code low part word (refer to units table) *
Long
4
x1000
32
Rise contact pressure unit code high part word (refer to units table) *
33
Drop contact flow low part word *
Long
4
x1000
34
Drop contact flow high part word *
35
Drop contact flow unit code low part word (refer to units table) *
Long
4
x1000
36
Drop contact flow unit code high part word (refer to units table) *
