Real time
Status and real time measures
The real time measurement is used for display curve or values during the cycle and not for the final
measurement.
Do not take or use the final results in this section, it is just to see the status of the device for the “Cycle
end” (bit 5) and “Key presence” (bit 15) information.
For the results, use only the FIFO list results structure or the Last results structure (see above)
Words
Meaning
Type
Bytes
Coeff
1
Program number.
Word
2
2
Number of results waiting in the results FIFO memory.
Word
2
3
Test type.
Word
2
4
Status:
Bit 0 = 1: pass part.
Bit 1 = 1: fail part maximum flow.
Bit 2 = 1: fail part minimum flow.
Bit 3 = 1: alarm.
Bit 4 = 1: pressure error.
Do not use these results while the Bit
5 (cycle end is not 1).
Use only Bit 5 (cycle end) and Bit 15
(key presence).
Bit 5 = 1: cycle end.
Word
2
Bit 6 = 1: recoverable part.
Bit 7 = 1: CAL error or drift.
Bit 8 = 1: Unused.
Bit 9 = 1: ATR error or drift.
Bits 10 / 11 / 12 / 13 / 14 = 1: Unused.
Bit 15 = 1: key presence.
Do not use these results while the Bit 5
(cycle end is not 1).
Use only Bit 5 (cycle end) and Bit 15
(key presence).
5
Step code (refer to steps table).
Word
2
6
Low pressure section word.
Long
4
x1000
7
High pressure section word.
8
Pressure unit code low part word (see units table).
Long
4
x1000
9
Pressure unit code high part word (see units table).
10
Flow low section word.
Long
4
x1000
11
Flow high section word.
12
Flow unit code low part word (refer to. Units table).
Long
4
x1000
13
Flow unit code high part word (refer to. Units table).
Examples
Pressure value = 207
Pressure: Words 6 and 7
On network:
Flow value = -0.108
Flow: Words 10 and 11
On network:
00032898h 207000(d)/1000 207
FFFFFF94h -108(d)/1000 -0.108
