SLMP ID for parameter SET/GET
Functionalities
R/W
ID
Length
Format
Comment
Parameters
R/W
001 - 499
4 bytes
Signed long,
Coeff * 1000
”Error! Reference source
not found.”
section
Extended menu bits
R/W
500
20 bytes
Array of bytes
“Error! Reference source
not found.” section
Select program
W
501
2 bytes
Unsigned short
Functions bits
R/W
502
20 bytes
Array of bytes
“Error! Reference source
not found.”
section
Program Name
R/W
503
12 bytes
ASCII Array
of 12 char
eg : « 123456789AB »
Number of FIFO results
R
504
2 bytes
short
Result export frame
R
505
128 bytes max
ASCII frame
Statistic cycle counter
R
506
16 bytes
(4 * DWORD)
Per program
Export frame
The character “→” corresponds to a tab HT (09(h)).
The character “” corresponds to a carriage return CR (0D(h)).
1
→
2
→
3
→
4
→
5
→
6
→
7
→
8
8’
9
→
10
→
#
Item
1
Personalization
2
Program number
3
Test result message
4
Test numeric value
5
Test unit
6
Pressure numeric value
7
Pressure unit
8
Alarm message
8’
Bar code
9
Date
10
Hour
Structure of statistic
Words
Meaning
Type
Bytes
1
Total number of parts
Unsigned
long
4
2
3
Number of good parts
Unsigned
long
4
4
5
Number of bad parts
Unsigned
long
4
6
7
Number of alarms
Unsigned
long
4
8
