ATEQ D620 - Page 25

D620.388.00_QS_UK_01
25 / 42
Capillary output connector
This connector has to be left to the atmosphere for indirect mode.
Instant fitting: 8, 10 or 12 mm diameter.
ATM 4 mm connector
This connector has to be left free to the atmosphere.
Instant fitting: 4 mm diameter.
ATM 6 mm connector
This connector has to be left free to the atmosphere.
Instant fitting: 6 mm diameter.
