ATEQ D670 Quick Start Guide

QSG_D670_389.00_EN_01_2020-06-18
13/42
Ref
Name
Description
1
TEST
Test outputs (option)
2
TEST
Test outputs (option)
3
TEST
Test outputs (option)
4
TEST
Test outputs (option)
5
TEST
Test outputs (option)
6
TEST
Test outputs (option)
7
-
Pneumatic input for valve piloting option
8
M1
To be connected to M1 – capillary 1 (option)
9
M2
To be connected to M2 – capillary 1 (option)
10
M2
To be connected to M2 – capillary 2 (option)
11
M1
To be connected to M1 – capillary 2 (option)
12
-
Pneumatic input for valve piloting option
13
ATM
Flow inputs before valves switching to be connected to test outputs on
the upper case
14
ATM
Flow inputs before valves switching to be connected to test outputs on
the upper case
15
ATM
Flow inputs before valves switching to be connected to test outputs on
the upper case
16
ATM
Flow inputs before valves switching to be connected to test outputs on
the upper case
17
-
Pneumatic input for valve piloting option
18
-
Pneumatic input for valve piloting option
19
J13
Temperature cable input (if capillary placed in the bottom case)
