CONFIGURING THE ASSOCIATED MEASUREMENTS
3. Select the program to configure and press
The parameters of the selected measurement
type are displayed.
4. Define the measurement cycle parameters.
See: Modifying a parameter.
MODIFYING A PARAMETER
Use this procedure to complete the test program setup.
The protection of the parameters is configurable. If the icon is displayed
at the bottom of the screen, you must insert the USB unlocking device or enter
a password before modifying a parameter.
On the PARAMETERS screen of the program (see: Preparing a program):
1. Press up/down to select the parameter to
modify, and then press .
An arrow is displayed on the right of the parameter
being modified.
2. Use the up/down keys to modify the parameter
value, and press to validate.
The arrow returns to the left of the modified
parameter.
3. Repeat these steps until all parameters are set.
4. To return to the MAIN MENU screen, press
Esc as many times as necessary.
