ATEQ F670 Quick Start

Quick start - F670
MR-36300C-U Quick start manual ATEQ F670 Page 6/25
2.3.1. 1) Examples of RS232 cables
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
ATEQ
Use
r
9 pin SubD
connector
9 pin SubD
connector
RX
TX
GND
RTS
CTS
RX
T
X
GND
RTS
CTS
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
A
TEQ
User
25
9 pin SubD
connector
25 pin SubD
connector
RX
TX
GND
RTS
CTS
RX
T
X
GND
RTS
CTS
2.4. J2 CONNECTOR PROFIBUS / MODBUS
1
5
9
6
Profibus: SubD 9 points female
connector.
2.5. J3 CONECTOR ANALOG OUTPUTS (OPTION)
Connection for analog outputs.
2 1
4
3
5
¾ Pin 1: sensor 1 (plus).
¾ Pin 2: sensor 1 (minus).
¾ Pin 3: sensor 2 (plus).
¾ Pin 4: sensor 2 (minus).
