G620 Option Bypass or Shut Off
Connection
Option / description
Air supply to 1
Connection of the air supply to the filter input (0.6 MPa)
2 to 3
Connection of the test output to the part under test (direct mode option)
4 to ATM
Connector left free to the atmosphere
