User interface
OVERVIEW
The user interface comprises a display and user keys located on the front panel.
1 Display
2 Cycle keys
3 Navigation keys
KEYS
Cycle keys
The cycle keys are used to start and to stop a measurement cycle.
Key
Name
Function
Start
On the Program screen, starts a measurement cycle and opens
the Measurement cycle screen.
Reset
Stops the measurement cycle in progress and returns to the
Program screen.
