Table 8.3—DL15ToolSpecications
9121-DL15-T
PROFINET Tool module provides one Ethernet port and supports Tool-ID through
the Master module. D‑Coded 4‑Pin M12 connector for Pronet communication,
5-Pin Mini Connector for US1 and US2 power, M12 5-Pin Female Connector
provided to support RFID Based TSI on Tool, Tool-ID 0-99999 adjustable with
thumbwheel switches. Supports Arc Prevention on the Master. Mates with DL10-M.
Connector(s)
(1) 5-Pin female Mini-Fast Connector for auxiliary power
(1) 4-Pin female M12 D-Coded Connector for PROFINET
(1) 5-pin female M12 TSI connector for RFID based Safety Switch
Electrical
Rating
US1+ and US2+ Power: 9 A, 12 to 30 VDC
Signal: 2 A, 30 VDC maximum
Tool-ID (5) Push-button switch reading 0–9 positions (00000-99999).
Weight 1.5 lbs (0.68 kg)
