7. Serviceable Parts
Refer to Section 9—Drawings for additional serviceable parts that are not listed in the following tables.
7.1 Master Module Serviceable Parts
Table 7.1—Master Module Mounting Fasteners
Part Number Qty Description
3500-1066020-21A 2
M6 x 20 Socket Head Cap Screw, SS, ND Microspheres, 0-3
uncoated lead threads. 5-7 coated threads. IFI525
7.2 Tool Module Serviceable Parts
Table 7.2—Tool Module Mounting Fasteners
Part Number Qty Description
3500-1066016-21A 2
M6 x 16 Socket Head Cap Screw, DIN 912 A4 S/S (316) ND
Ind. Microspheres Epoxy, Yellow. 0-3 uncoated lead threads. 5-7
coated threads.
7.3 Accessories
Table 7.3—Accessories
Part Number Description
3690-0000064-60 Brush, Blue Nylon All Purpose (Contact Pin Cleaning)
9121-PLD-PLUG TSI Teach Plug for the DL15 Tool
9120-DC45-Plug TSI Teach Plug for the DL10 Tool
9120-C-4EM-4EF TSI Cable (for 4-Pin Connector) DL10 Tool
3690-0000049-00 Closure Cap for Female Mini receptacles
