Oil capacity cu. ft. 0.57
Sound pressure level (according to ISO 2151:2004) dB(A) 67
Fan data
Model Static pressure head Flow Maximum
absorbed
power
GA 18 VSD+, GA 22 VSD+ 125 Pa (0.50 in WC) 5500 m³/h (3250 cfm) 450 W
GA 26 VSD+, GA 30 VSD+ 130 Pa (0.52 in WC) 6500 m³/h (3800 cfm) 700 W
GA 37 VSD+ 150 Pa (0.60 in WC) 8000 m³/h (4700 cfm) 1000 W
9.5 Technical data controller
General
Supply voltage 24 V AC /16 VA 50/60Hz (+40%/-30%)
24 V DC/0.7 A
Type of protection IP54 (front)
IP21 (back)
• Operating temperature
range
• Storage temperature
range
• -10°C…..+60°C (14 °F .....140 °F)
• -30°C…..+70°C (-22 °F ......158 °F)
Permissible humidity Relative humidity 90%
No condensation
Mounting Cabinet door
Digital outputs
Number of outputs 9
Type Relay (voltage free contacts)
Rated voltage AC 250 V AC / 10 A max.
Rated voltage DC 30 V DC / 10 A max.
Digital inputs
Number of inputs 10
Supply by controller 24 V DC
Supply protection Short circuit protected to ground
Input protection Not isolated
Instruction book
114 2920 7110 05
