Electric cabinet, typical example
Reference Designation
T1 Transformer
Q15 Circuit breaker
Q1 Circuit breaker
K15 Contactor
Z1 EMC filter
U1 Frequency converter
Electrical diagrams
The complete electrical diagram can be found in the electric cabinet as well as in the technical
documentation, supplied with the unit.
Instruction book
24 2920 7110 05
