10 Outlet cooling air grating of the air cooler and the oil cooler.
11 Outlet cooling air grating of the dryer.
12 Bypass system to bypass the dryer during service operations (available as an option, consult
Atlas Copco).
Safety
Apply all relevant safety precautions, including those mentioned in this book.
Outdoor/altitude operation
The compressors are not designed for outdoor use.
The compressors can only be used in temperatures above 0 °C (+32 °F). If frost might occur, the
appropriate measures should be taken to avoid damage to the machine and its ancillary
equipment. In this case, consult Atlas Copco.
Also if operating above 1000 m (3300 ft), consult Atlas Copco.
Moving/lifting
The compressor can be moved by a lift truck using the slots in the frame. Take care not to
damage the bodywork during lifting or transport. Before lifting, reinstall the transport securing
bolts. Make sure that the forks protrude from the other side of the frame. The compressor can
also be lifted after inserting beams in the slots. Make sure that the beams cannot slide and that
they protrude from the frame equally. The chains must be held parallel to the bodywork by chain
spreaders in order not to damage the compressor. The lifting equipment must be placed in such
a way that the compressor is lifted perpendicularly. Lift gently and avoid twisting.
In case of units equipped with the Lifting Device Option, it is not allowed to lift the
compressor if the canopy parts or lifting supports are not completely installed. When the
compressor is being lifted, it is also forbidden to come under the load or to perform
maintenance activities to it.
Acclimatization
When moving the compressor into an installation room, forming of condense can occur
on some components.
To avoid dew harming of electrical components, ensure at least 2 hours of
acclimatization before switch on the compressor.
Instruction book
58 2920 7110 05
