• The water inlet temperature of the energy recovery system
• The water outlet temperature of the energy recovery system
Modifying settings
If the programmed warning settings for the water temperatures are exceeded, a warning
indication is shown on the controller:
Temperature input Minimum
setting
Nominal
setting
Maximum
setting
Water inlet temperature of energy recovery ˚C 0 70 99
Water inlet temperature of energy recovery ˚F 32 158 210
Energy recovery water outlet temperature ˚C 0 90 99
Energy recovery water outlet temperature ˚F 32 194 210
To modify a setting, consult the relevant section in the description of the controller.
Recoverable energy
The recoverable energy can be calculated from:
RECOVERED ENERGY (kW) = 4.2 x water flow (l/s) x water temperature rise (˚C)
In the tables below, typical examples are given.
Data for low temperature rise/high water flow systems
Parameter Unit
GA 18 VSD
+
GA 22 VSD
+
GA 26 VSD
+
GA 30 VSD
+
GA 37 VSD
+
Recoverable energy kW 15.8 19.4 22.9 26.4 32.6
Recoverable energy hp 21.5 26.3 31.1 35.9 44.3
Water flow l/min 22.7 27.8 32.8 37.9 46.7
Pressure drop mbar 150 170 250 330 500
Water flow cfm 0.8 1.0 1.2 1.3 1.6
Pressure drop in WC 60 68 100 132 200
Temperature at inlet ˚C 50 50 50 50 50
Temperature at inlet ˚F 122 122 122 122 122
Temperature at outlet ˚C 60 60 60 60 60
Temperature at outlet ˚F 140 140 140 140 140
Data for high temperature rise/low water flow systems
Parameter Unit
GA 18 VSD
+
GA 22 VSD
+
GA 26 VSD
+
GA 30 VSD
+
GA 37
VSD
+
Recoverable energy kW 15.8 19.4 22.9 26.4 32.6
Recoverable energy hp 21.5 26.3 31.1 35.9 44.3
Water flow l/min 5.7 6.9 8.2 9.5 11.7
Pressure drop mbar 25 25 35 35 50
Water flow cfm 0.2 0.2 0.3 0.3 0.4
Instruction book
76 2920 7110 05
