Applications
Type of applicationField
Trenchwork for utilities,
foundation work
General construction work
Heavily reinforced concrete,
demolition of power stations
and bridges
Demolition
Primary breakingRock mining/breaking
Secondary breaking, bench
leveling foundation work
Bench levellingTunneling*, mining*
Tunnel driving
Breaking up slagHigh temperature applications*
Demolition, Deepening
shipping channels
Underwater applications*
* only after consulting the Atlas Copco Customer Center/Dealer
in your area
Guarantee
The guarantee or product liability will be invalidated
by the following:
● Use other than intended
● Maintenance work not being carried out or being
carried out incorrectly
● The use of the wrong consumables
● The use of non-approved parts
● Damage due to wear
● Special applications without the required safety
facilities
● Damage due to improper storage
● Changes not carried out by or in consultation with
the manufacturer
Removing the packaging
♦
Remove all the packaging material.
♦
Dispose of it in accordance with the applicable
provisions.
♦
Check that the delivery is complete.
♦
Check the delivery for visual damage.
♦
If any defects are found, consult the Atlas Copco
Customer Center/dealer in your area.
Scope of delivery
The hydraulic breaker is delivered complete with:
● Hydraulic breaker
● Test gauge lower wear bush
● Safety and Operating instructions
● Spare parts list
● EC Declaration of Conformity
Accessories as ordered:
● Working tool
● Hoses
● Service box
Special accessories as ordered:
● e.g. adapter plate with Allen screws and pairs of
lock washers
● e.g. base plate to construct an adapter plate with
Allen screws and pairs of lock washers
● e.g. hydraulic fittings for the carrier
● e.g. piston retainer
● e.g. calliper upper wear bush
17© 2012 Atlas Copco Construction Tools GmbH | No. 3390 5096 01 | 2012-04-26
Original instructions
OVERVIEWHB 3100, 3100 DP, 3600, 3600 DP, 4100, 4100 DP,
4700, 4700 DP
