Atlas Copco HC 150

Cylinder end positions
♦
Reposition the carrier to avoid working with the
cylinder in its end positions.
Avoid operating the hydraulic attachment when the
carrier stick and bucket cylinder are in one of their
end positions. These end positions have damping
facilities; the hydraulic cylinder may be damaged by
prolonged use while in its end positions.
