Hydraulic compactor HC 850 - HC 1055
HC 1055HC 1050HC 850Model
20 - 40 t20 - 40 t9 - 20 tCarrier weight class
1
44092 88185 lbs44092 - 88185 lbs19842 - 44092 lbs
1135 kg1130 kg880 kgService weight
2
2502 lbs2491 lbs1940 lbs
Dimensions
786 mm786 mm764 mmHeight
30.94 in.30.94 in.30.08 in.
864 x 1364 mm864 x 1364 mm710 x 1272 mmPlate (width x length)
34.02 x 53.70 in.34.02 x 53.70 in.27.95 x 50.08 in.
0.90 m
2
0.90 m
2
0.68 m
2
Plate coverage
1395.00 in.
2
1395.00 in.
2
1054.00 in.
2
11.4 t10.5 t7.3 tImpact force
25133 lbs23149 lbs16094 lbs
2200 n/min2200 n/min2200 n/minVibration frequency
150 bar150 bar150 barOperating pressure
2176 psi2176 psi2176 psi
189 l/min151 l/min114 l/minOil flow
49.9 gal (US)/min39.9 gal (US)/min30.1 gal (US)/min
10 bar10 bar10 barMaximum return line pressure
150 psi150 psi150 psi
3.7 l3.7 l3.7 lMotor oil quantity
0.98 gal (US)0.98 gal (US)0.98 gal (US)(in rotor housing)
71 L
P
dB(A)76 L
P
dB(A)66 L
P
dB(A)Sound pressure level
(measured r = 10 m)
106 L
WA
dB(A)106 L
WA
dB(A)106 L
WA
dB(A)Sound power level
3
(guaranteed)
M42 x 2M42 x 2M36 x 2Connecting thread
conical seal 24°conical seal 24°conical seal 24°(»P« and »T«)
JIC 16, 1 5/16" UNFJIC 16, 1 5/16" UNFJIC 12, 1 1/16" UNFPort connectors
(type: male thread)
Min. inside diameter
25 mm25 mm20 mmHoses
0.98 in.0.98 in.0.79 in.
25 mm25 mm20 mmPipes
0.98 in.0.98 in.0.79 in.
Pipework
30 x 2.5 mm30 x 2.5 mm25 x 2.5 mmDiameter and wall thickness
1.18 x 0.10 in.1.18 x 0.10 in.0.98 x 0.10 in.
MB 1200 - MB 1700MB 1200 - MB 1700MB 500 - MB 1000Hole pattern (adapter plate)
1
Weight apply to standard carriers only.
Any variations must be agreed with Atlas Copco and / or the carrier manufacturer prior to attachment.
2
Hydraulic compactor including adapter plate of medium size
Please note that the service weight can be considerably higher, depending on the adapter plate.
3
EN ISO 3744 in accordance with Directive 2000/14/EC.
© 2014 Construction Tools EOOD | No. 3390 5121 01 | 2014-11-19
Original instructions
52
HC 150, 350, 450, 850, 1050, 1055TECHNICAL SPECIFICATIONS
