Atlas Copco LG 504 User Manual

Stopping the engine, Hatz manual start
1. Move the throttle control handle to idling position.
For non EPA throttle control:
Move the throttle control handle to half throttle,
position (A).
For EPA throttle control:
Pull up the stop (B) to release the throttle control
handle. Move the throttle control handle to half
throttle, position (A).
NOTICE The EPA throttle control has three
fixed positions. Make sure the throttle control
handle is in a fixed position.
2. Allow the engine to idle for a few minutes.
3. Stop the engine by moving the throttle control
handle to position (C).
For non EPA throttle control:
For EPA throttle control:
© 2016 Construction Tools EOOD | No. 9800 1721 01 | 2016-04-07
Original instructions
22
LG 504Safety and operating instructions
