9 Options available for QAS 60 units
9.1 Circuit diagrams
The engine control circuit diagrams and the power
circuit diagrams for the standard QAS 60 units, for
the units with options and for the units with combined
options are:
Power circuit
Unit Circuit
QAS 60 Pd 9822 0996 10
QAS 60 Pd - 2V-50Hz 1ph 9822 0996 11
QAS 60 Pd - 2V-50 Hz 9822 0996 12
Controller circuit
Unit Circuit
QAS 60 Pd Qc1002™ 9822 0996 05
QAS 60 Pd Qc2002™ 9822 0996 06
QAS 60 Pd Qc4002™ MkII 9822 0996 18
9.2 Overview of the electrical
options
The following electrical options are available:
– Automatic battery charger
– Battery switch
– Engine coolant heater
– Outlet sockets (S) - Set 1
– Outlet sockets (S) - Set 2
– Outlet sockets (S) - Set 3
– Single frequency with electronic speed control
(SF)
– Dual frequency with electronic speed control (DF)
– Electronic speed regulator
– Dual voltage (2V)
– Earth leakage relay
– IT-relay
– “Electricité de France” (EDF)
–COSMOS™
–COC box
