Main parts
A
E
B
D
F
C
G
SRD 20
A
G
B
D
F
C
E
SRD 25
A. Handle
B. Air inlet nipple
C. Drill steel retainer
D. Throttle lever
E. Extra flushing
F. Silencer
G. Water inlet
Labels
The machine is fitted with labels containing
important information about personal safety and
machine maintenance. The labels must be in such
condition that they are easy to read. New labels
can be ordered from the spare parts list.
Data plate
A
B
C
D
E
xx
xxxxx
A. Machine type
B. Maximum permitted compressed air pressure
C. Serial number
D. The warning symbol together with the book
symbol means that the user must read the
safety and operating instructions before the
machine is used for the first time.
E. The CE symbol means that the machine is EC-
approved. See the EC declaration which is
delivered with the machine for more
information. If the CE symbol is missing, it
means that the machine is not EC-approved.
Safety label
To avoid injury, before using or servicing tool, read
and understand separately provided safety
instructions.
Safety and operating instructions SRD 20, 25
12 © Construction Tools PC AB | 9800 1883 01 | 2017-05-31
Original instructions
