15
TEX 140PS 150PE 180PS 190PE 220PS 230PE 270PS 280PE
© 2007 Atlas Copco Construction Tools AB
|
No. 9800 0800 01
|
2007-10-01
Overhaul instructions
Piston
1
Tool retainer
1
2
3
Û
Insert the spring pin with the opening pointing in a
45° angle downwards and outwards.
Air inlet
1
