Atlas Copco XA(S) 300 DD7

- 21 -
Reference Name
F1 Circuit breaker
G1 Alternator
G2 Battery
H1 Lamp temperature alarm
H2 Lamp general alarm
K0 Starter solenoid (part of M1)
K1 Relay
K2 Relay
K3 Relay
K4 Relay
K5-K6 Relay heater plug
M1 Starter motor
P1 Hourmeter
P2-P3 Heater plug
S1 Contactswitch (Off-On-Override-
Start)
S2 Temperature switch engine
S3 Oil pressure switch
S4 Temperature Lamptest switch
S5 Temperature switch compressor
S6 Coldstart switch
V1 Diode
V2 Diode
Y1 Fuel solenoid valve
