selected working pressure and the corresponding
unloading pressure.
— Cooling System
Engine and compressor are provided with a radiator and oil
cooler. The cooling air is generated by a fan, driven by the
engine.
— Safety Devices
A thermal shut-down switch protects the compressor
against overheating. The air receiver is provided with a
safety valve.
The engine is equipped with low oil pressure and high
coolant temperature shut-down switches and an
alternator/V-belt protection system.
— Frame and Axle
The compressor/engine unit is supported by rubber buffers
in the frame.
The standard XAS 185 JD7 is equipped with a non-
adjustable drawbar with a towing eye and road lighting.
As an option, the unit can be equipped with electric,
hyduralic and/or parking brake.
When driving backwards the hyduralic brake is not
engaged automatically.
— Bodywork
The bodywork has openings at the shaped front and rear
end for the intake and outlet of cooling air and a specially
hinged canopy for maintenance and service operations.
The bodywork is partially lined with sound-absorbing
material.
— Lifting Eye
A lifting eye is accessible through the roof panel at the top
of the unit.
— Control Panel
The control panel grouping the air pressure gauge, control
switch etc., is placed at rear of air compressor.
— Data Plate
The compressor is furnished with a data plate located on
the front side of the unit showing the compressor type,
serial number, maximum final pressure and normal working
pressure.
Place
example of
data plate
