Atlas Copco XRVS 1000 CD7 IT4 HOP - Page 14

- 14 -
Reference Name
AFE Air Filter Element
AFc Air Filter (compressor)
AFe Air Filter (engine)
AFS Air Filter Switch
AOV Air Outlet Valve
AR Air Receiver
BVof Bypass Valve oil filter
BOsv Blow Off System Solenoid Valve
CCubicle
CEhp Compressor Element (high pressure)
CElp Compressor Element (low pressure)
CH Coupling Housing
CU Control Unit
DAXiv DrillAirXpert Inlet Valve
DAXsm DrillAirXpert Stepper Motor
DE Dust Evacuator
DP Drain Plug
E Engine
EW Electrical Wiring
FFan
MPV Minimum Pressure Valve
OC Oil Cooler
OFc Oil Filter (compressor)
OFe Oil Filter (engine)
Reference Name
OSE Oil Separator Element
OSV Oil Stop Valve
OT Oiltronix
PSai Pressure Sensor (air inlet)
PSlp Pressure Sensor (low pressure)
SC Safety Cartridge
SL Scavenge Line
SV Safety Valve
SVbos Safety Valve(blow off system)
TBV Thermostatic Bypass Valve
TShp Temperature Switch (high pressure)
TSlp Temperature Switch (low pressure)
WPS Working Pressure Sensor
