as required using the scroll keys, i.e. in the example above change “18” into “17” using the arrow up
key (1).
• If necessary, press the tabulator key (2) to go to the next field to be modified, the minutes indication
and the start/stop/pressure band indication.
• Press the key “Program” to program the new command or the key “Cancel” to quit without
reprogramming.
Adding a command at the end of an existing list
• Starting from the Main screen, press the key “Menu” (F1), press the arrow down key until the option
“Modify Parameters” is followed by a horizontal arrow.
• Activate the menu by pressing the tabulator key (2).
• Use the arrow down key (1) to scroll until the option “Clock Function” is followed by a horizontal
arrow. Press the tabulator key, following screen appears:
“Clock Function”
“Not Activated”
.
“Menu” “Modify” “Delete”
F1 F2 F3
Suppose the command to stop the compressor at 18:00 must be added to the list of Monday
• Press the tabulator key (2), following screen appears:
“Monday”
“Tuesday”
“Wednesday”
“Menu” “Delete”
F1 F2 F3
• Scroll through the display until “Monday” is followed by a horizontal arrow. Press the tabulator key
(2). Scroll through the compressor start/stop/pressure band commands until the first empty command
line is indicated by the horizontal arrow.
• Press the key “Modify”; the first two digits start blinking. Enter “18:00 Compressor Stop” using the
scroll keys (1) to modify a field and the tabulator key (2) to jump from one field to another.
• Press the key “Program” to program the new command or the key “Cancel” to quit without
reprogramming.
Adding a command between two existing commands
Suppose the command “17:00 Pressure Band 2” must be added to the following list:
• 06:00 Start Compressor
• 06:00 Pressure Band 1
• 18:00 Stop Compressor
The regulator does not allow to enter a new command which is situated before the last command in the list
timewise.
Scroll through the display until the command before which the new command must be entered is followed
by a horizontal arrow (in the example above: “18:00 Stop Compressor”) and press the key “Modify”.
Instruction book
98 2920 1815 04
