Atlas Copco ZR 110 User Manual

Part number V in liter
(US gal/Imp gal/
cu.ft)
MWT in mm CA in
mm
H
in
mm
D in
mm
CF
1627 2472 99 270
(71.33/59.40/9.53)
Cover:
• Cylindrical part:
10.0
• Torispherical part:
13.5
Bottom:
• Cylindrical part:
10.0
• Torispherical part:
12.0
• Cylindrical cooler:
16.5
Cover:
1.0
Bottom:
1.0
898 713 Cover: 0.8
Bottom: 0.8
Used abbreviations
V: Internal volume (Liter)
MWT: Minimum wall thickness as manufactured (mm)
CA: Corrosion allowance (mm)
H: Height of the vessel (mm)
D: Diameter of the vessel (mm)
CF: Casting factor (according ASME BPVC section VIII div 1)
Heat exchanger ZR 160 up to ZR 275
Reference Name
1 Intercooler
2 Aftercooler
3 Position of data plate
Instruction book
320 2920 1815 04
