Heat exchanger ZR 160-275
PED Category CAT II
Design code ASME BPVC Section VIII, div 1
Material SA-395
Bolts 8.8
Interval of periodic
inspection by 3rd
party (1)
5 years or the frequency as given in national legislation
Intercooler Aftercooler
Casting factor 0.8 0.8
Minimum wall
thickness after
corrosion
Covers : 8 mm
Shell : 10 mm
Covers : 8 mm
Shell : 10 mm
Shellside Tubeside Shellside Tubeside
Medium Water, group 2 Air, group 2 Water, group 2 Air, group 2
Volume 92 l 21.4 l See intercooler 17.6 l
Design pressure 15 bar 4.5 bar 15 bar 13.7 bar
Design temperature 95 °C 240 °C 95°C 240 °C
(1) The maintenance instructions given in the user manual must be applied by the user.
Instruction book
2920 1815 04 321
