“Monday”
“Tuesday”
“Wednesday”
“Menu” “Delete”
F1 F2 F3
• Use the scroll keys (1) until the day on which a command must be programmed is followed by a
horizontal arrow. Press the tabulator key (2); following screen appears:
--:-- ----------------------
--:-- ----------------------
--:-- ----------------------
“Menu” “Modify” “Delete”
F1 F2 F3
• Press the key “Modify” (F2). The first two dashes will flash. Use the scroll keys (1) to enter “06”.
Press the tabulator key (2) to jump to the following two dashes. Use the scroll keys to enter “15”.
Press the tabulator key to jump to the row of dashes. Use the scroll keys to enter the command “Start
Compressor”.
• Press the key “Program” to program the command : “06:15 Start Compressor”.
• Press the arrow down key (1): the horizontal arrow indicates that the second line is accessible. Press
the key “Modify” and modify this line in a similar way to the following command: ”06:15 Pressure
Band 1”.
• Press the key “Menu” (F1) and scroll to “Friday”:
“Thursday”
“Friday”
“Saturday”
“Menu” “Delete”
F1 F2 F3
• Programming the command to change over at 18 o’clock to “Pressure Band2” is carried out in a
similar way as described above.
• Press the key “Menu” (F1) and scroll to “Saturday”. Programming the command “18:00 Compressor
Stop” is carried out in a similar way as described above.
Activating/deactivating the timer
• The timer can only be activated if at least one start/stop command is programmed.
• Starting from the Main screen, press the key “Menu” (F1).
• Use arrow down key (1) until the option “Modify Parameters” is followed by a horizontal arrow.
• Press the tabulator key (2) to activate the menu.
• Use the arrow down key until the option “Clock Function” is followed by a horizontal arrow, press
the tabulator key (2), following screen appears:
Instruction book
96 2920 1815 04
