S E C T I O N
4
Operators Manual ATLAS CARTS
22
Operators Manual ATLAS CARTS
Vehicle Specifications
Manufacturer Atlas Carts
Model Name Two Passenger
Model Number 2N
Manufacturer Data
Vehicle Length 92.5 in. (2350 mm)
Vehicle Width 52.36 in. (1330 mm)
Vehicle Height 81 in. 72.8 in. (1859 mm)
Ground Clearance 5.3 in. (135 mm)
Wheel Track Front 33.86 in. (860 mm)
Wheel Track Rear 38.19 in. (970 mm)
Wheelbase 65.7 in. (1670 mm)
Turning Radius 161.4 in. (4.1 M)
Step in Height 12.25 in.
Dimensions
Forward Speed (On Level Ground) 20 mph
Operational Temperature Range -4 degrees F to 122 degrees F
(-20 degrees C to 50 degrees C)
Performance
Motor Type KDS AC 5KW
Motor Horsepower Rating 6.7
Battery Type 210 AH, 48V Lithium-Ion
Battery Quantity 1
AC Voltage Input 85–270VAC
AC Current Input 12.0A @ 120VAC; 6.1A @220V Max.
Frequency 50/60Hz
DC Voltage 68V Max.
DC Current 25A Max.
Electrical
Maximum Number of Occupants 2
Vehicle Curb Weight Includes Fluids 1,036 lbs. (470 kg)
and 48V Lithium 210AH Battery
Maximum Payload 600 lbs. (408.2 kg)
Gross Vehicle Weight Rating (GVWR) 1,636 lbs. (951.2 kg)
Includes total vehicle weight, fluids,
battery, passenger, and cargo
Vehicle Weight and
Load Capacities
Brake Fluid DOT 4
Transaxle Fluid Capacity .65 liters; 85W-90GL-5
Mechanical
If the rated capacities of the vehicle are exceeded, property damage,
serious personal injury, or death can occur.
Do not exceed the rated capacity of the vehicle. The stated rated capacity
is for level surfaces only.
Excess weight in the vehicle can aect the vehicle handing, or cause
component failure, resulting in loss of control of the vehicle.
Do not use the vehicle to tow another vehicle or a trailer.
