S E C T I O N
6
Operators Manual ATLAS CARTS29
Vehicle Maintenance
Checking Tire Pressure
Wheel Assembly Removal
Wheel Assembly Installation
To check the tire pressure:
1. Remove the cap on the valve stem.
2. Measure the tire pressure with gauge.
3. Recommended tire pressure for front and rear is 20 PSI for Innova 23x10-14
tires. For all other tires, please contact your authorized Atlas dealer.
4. Adjust tire pressure as necessary.
Correct tire pressure is important for maximum vehicle performance and
safety. All tires should maintain the correct tire pressure.
Before attempting to remove a wheel, first disable the vehicle by turning the
key to the OFF position:
1. Remove the center cap.
2. Loosen all four lug nuts. DO NOT REMOVE THE LUG NUTS YET.
3. Lift the vehicle. See pages 27 and 28 for correct vehicle lifting procedures.
4. Remove the wheel assembly.
Correct tire pressure is important for maximum vehicle performance and
safety. All tires should be the correct tire pressure.
1. I f the vehicle is already in the lifted position, proceed to step 2.
Note: If the vehicle needs to be relifted for any reason, see pages 27
and 28 for correct vehicle lifting procedures.
2. Align the wheel assembly onto the hub.
3. Install all four lug nuts. Snug up the lug nuts but do not final tighten yet.
4. Lift the vehicle just enough so the jack stands can be removed.
5. Remove jack stands.
6. Lower the vehicle to the ground and remove any wheel chocks.
7. Final tighten the lug nuts to the recommended torque specification
of 93 ft.lbs.
8 If center cap was removed, reinstall the center cap now.
