Operation And Use 28
Kwik Bay
PLIOT LAMP (2)
• It shows that the electric circuit is powered
LIFTING BUTTON (3)
• When pressed, the electric circuit for the lift operates the motor and
hydraulic circuit to raise the lift
LOWERING BUTTON (4)
• When pressed, the lift will be raised a little bit to release the safety, and a few
seconds later the lift begins to descend under its weight and the load lifted
SAFETY ENGAGING BUTTON (5)
• When pressed, the lowering solenoid valve operates the hydraulic circuit to
lower the lift to engage the nearest mechanical safeties.
8.2 To Raise The Lift
It is extremely forbidden to load the vehicle when the mobile
wheels are on the lift. Failure to do so can damage the lift
severely.
The lift must be raised at least 12” off of the ground before
taking the load.
