Product Description 12
Kwik Bay
Product Description
Lift Description (Ref. Figure 1)
The surface mounted lift has been designed for the lifting of motor-vehicles for
maintenance. The maximum lifting weight is as specifi ed on the serial plate. All
mechanical frames, such as platforms, extensions, base frames and arms have
been built in steel plate to make the frame stiff and strong while keeping a low
weight The electro hydraulic operation is described in detail in Chapter 8.
Figure 1 – Lift
This chapter describes the lift’s principal elements, allowing the user to be
familiar with the machine. As shown in fi gure 1, the lift is composed of two
8
7
6
4
5
3
2
1
